• Built-in Components: 6 DMIC microphone array, digital PTZ camera, 1 full range ported speaker, cable management & retention system, Multi-Mount, integrated motorized privacy shutter, Logitech Collab OS platform
• Enclosure: All-in-one enclosure with field replaceable front cover
• Device Management: Logitech Sync
• Displays Supported: 1 (2nd display support is coming soon)
• Display Resolution: 1080p
• Network Protocol Support: IPv4, IPv6
• Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file

Camera

• Digital Pan: ±48° at 4x zoom
• Digital Tilt: ±32° at 4x zoom
• Zoom: 4X HD digital zoom
• Diagonal Field of View: 120°
• Horizontal Field of View: 113°
• Vertical Field of View: 80°
• Resolution: 4K

Speakers

• Driver: 2.2 in(55 mm) with bass reflex enclosure and patented suspension design
• Sensitivity: 83 dB SPL @1W +/-2dB @ 1 meter
• Rated Power: 8W
• THD at 1W, 1kHz: <2%
• Speaker Sampling Rate: 48KHz
• Impedance: 4 Ohms

Microphones

• Frequency Response: 90Hz – 16kHz
• Sensitivity: -36dBFS +/-1 dB @ 1Pa
• Microphone data rate output: 48 kHz
• Pickup Range: Up to 23 ft (7m)
• Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
• Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
• Noise suppression: AI-based de-noising algorithm

Interfaces

• HDMI Out: 1
• HDMI In: 1
• USB: 1x Type A USB 3.1, 1x Type C USB 3.1
• Network: 10/100/1G Ethernet
• WiFi: 802.11a/b/g/n/ac
• Bluetooth: Bluetooth® Low Energy

Power and Cables

• Power supply: Auto-sensing
• Operating Voltage/Power: 100-240V, 19V, 2.1A
• Power Supply Dimensions: 4.48 in (114 mm) x 1.85 in (47 mm) x 1.27 in (32.3 mm)
• DC Cable: 5 ft (1.5 m)
• AC Cable: 3.3 ft (1 m)
• HDMI 1.4 Cable: 6.5 ft (2 m)
• USB A to USB C 3.0 Cable: 7.2 ft (2.2 m)

Environmental

• Operating Temperature: 0 to 40°C
• Storage Temperature: -25 to 70°C
• Humidity: 10 to 90%
